15″ Flat Screen Touch Screen LCD Monitor 10 Points Capacitive for Cash Register Restaurant
15-inch touch display with capacitive or resistive touch options, perfect for POS systems and cashier use.
High-definition 1024×768 resolution ensures clear visuals, ideal for retail and payment processing.
Versatile connectivity with VGA, HDMI, and USB ports, plus customizable interfaces upon request.
Durable and responsive touchscreen supports smooth operation in busy checkout environments.
Tailored for business needs—special interface customizations available to fit your unique setup.
- Description
15 Inch Touch Screen Monitor Specification
| Panel size | 15 inch TFT-LCD Capacitive/Resistive Touch Screen Monitor | ||||||
| Standard Resolution | 1024*768/60HZ | ||||||
| Number of Colors | 16.2M | ||||||
| Brightness | 300cd/m2 | ||||||
| Response time | 5ms | ||||||
| View angle | Horizontal:170° | ||||||
| Vertical:170° | |||||||
| Contrase ratio | 300:01:00 | ||||||
| Video input format | (analog) RGB | ||||||
| Connector | VGA+HDMI+USB | ||||||
| Frequency | 30~80KHz/60~75Hz | ||||||
| Power supply | External Power Supply:100 to 240V (DC 12V) | ||||||
| Operation Environment | Workable Temperature:-10 to 60°C Storage temperature:-20 to 70°C | ||||||
| Operate relative humidity:20% to 80%;storage relative humidity:10% to 90% | |||||||
| Touch model | Capacitive Multi/Single Resistive Touch | ||||||
| Optional | (5-wire resistive touch,SAW,Infrared touch optional) | ||||||
| Duration | 50000hours | ||||||
| touch validity | >1,000,000 | ||||||
| Net weight | 2.0 Kgs/pcs,include stable base | ||||||
| Gross weight | 2.5 Kgs/pcs,include stable base | ||||||
| Power consumption | Max 30W | ||||||
| Setup (optional) | 1) provide wall brackets for wall-mounting, VESA 75mm&100mm | ||||||
| 2) provide stable mental base to support the monitor | |||||||
| OSD control | AUTO,+,POWER,-,MENU | ||||||
| brightness,contrast ratio,auto adjustment,phase position,clock,Languages,function,Install,reset | |||||||
| Touch interface | USB | ||||||
| Touch response time | 2ms | ||||||
